# Lecture 09: Fair Locks

## Last Week

A Tale of Two Pups

## Mutual Exclusion

Safety Goal:

• Both dogs are not simultaneously out in the yard
• mutual exclusion property

Liveness Goal:

• If a dog needs to go outside, eventually one does

## A(n Aysmmentric) Protocol I

When Finn needs to go out:

1. Raise flag

2. While Scott’s flag is raised, wait

3. Let Finn out

4. When Finn comes in, lower flag

## A(n Aysmmentric) Protocol II

When Ru needs to go out:

1. Raise flag

2. While Will’s flag is raised:

1. lower flag

2. wait until Will’s flag is lowered

3. raise flag

3. When Scott’s flag is up and Will’s is down, release Ru

4. When Ru returns, lower flag

## Crucial Observation

Before letting a dog out, both Scott and Will do:

1. raise flag
2. see other’s flag down
3. let dog out

## Mutual Exclusion & Timelines

Claim. If a dog wants to go out, eventually some dog will.

Why?

## Question

Is the protocol fair?

## Fairness Condition

Safety Goal:

• Both dogs are not simultaneously out in the yard
• mutual exclusion property

Liveness Goals:

• If a dog needs to go outside, eventually one does
• If a dog needs to go outside, eventually that dog does
• starvation-freedom property

# Peterson Lock

## Back to Computers

Two processes (threads) want to access a shared resource

• e.g., increment Counter object

Assume:

• processes have IDs 0 and 1
• ThreadID.get() returns the ID of the thread calling the method
• boolean[] flag
• flag[i] == true if process i wants to use resource
• int victim
• victim == i if process i is willing to wait (like Ru)

## Peterson Lock Idea

Similar to asymmetric protocol with Finn and Ru, but can switch roles.

To obtain lock:

1. indicate intent: set my flag to true
2. defer to other thread: set myself as victim
3. wait until either
• other thread’s flag is false, or
• I am not victim

To release lock:

1. set my flag to false

## Peterson lock Pseudocode

	public void lock() {
int i = ThreadID.get(); // get my ID, 0 or 1
int j = 1 - i;          // other thread's ID

flag[i] = true;         // set my flag
victim = i;             // set myself to be victim
while (flag[j] && victim == i) {
// wait
}
}


## Peterson unlock Pseudocode

	public void unlock() {
flag[i] = false;
}


## Goals

Mutual Exclusion. If both threads concurrently call lock(), then both cannot return until other calls unlock().

Starvation Freedom. If thread i calls lock() then eventually thread i returns.

Question. Why does Peterson lock achieve these properties?

## Proof of Mutual Exclusion I

Suppose not…

• $A$ and $B$ concurrently call lock()
• both return before other calls unlock()

In this case we say both threads enter critical section

## Proof of Mutual Exclusion II

Atomic operations:

• Actions of $A$:
• $(A.1)$ writes flag[A] = true
• $(A.2)$ writes victim = A
• $(A.3)$ reads flag[B]
• $(A.4)$ reads victim
• Actions of $B$:
• $(B.1)$ writes flag[B] = true
• $(B.2)$ writes victim = B
• $(B.3)$ reads flag[A]
• $(B.4)$ reads victim

## Proof of Mutual Exclusion III

Suppose $(B.2) \to (A.2)$:

• i.e., $A$ wrote to victim last

• if not, continue argument with roles of $A$ and $B$ reversed

## Conclusion I

The Peterson lock satisfies mutual exclusion!

## Starvation Freedom I

Claim. If thread $A$ calls lock(), eventually the method will return.

	public void lock() {
int i = ThreadID.get(); // get my ID, 0 or 1
int j = 1 - i;          // other thread's ID
flag[i] = true;         // set my flag
victim = i;             // set myself to be victim
while (flag[j] && victim == i) { /*wait*/ }
}


Case 1. $A$ reads flag[B] == false or victim == B.

## Starvation Freedom II

Claim. If thread $A$ calls lock(), eventually the method will return.

	public void lock() {
int i = ThreadID.get(); // get my ID, 0 or 1
int j = 1 - i;          // other thread's ID
flag[i] = true;         // set my flag
victim = i;             // set myself to be victim
while (flag[j] && victim == i) { /*wait*/ }
}


Case 2. $A$ reads flag[B] == true and victim == A.

## Starvation Freedom III

Assumption. Once thread B obtains lock, eventually B calls unlock()

	public void unlock() {

What then happens to thread A?
