Lecture 36: NP, Completed

$ \def\verify{ {\mathrm{verify}} } $

COSC 311 Algorithms, Fall 2022


  1. Final Exam: Friday, Dec. 16 9:00–12:00
    • same format as midterms
    • ~8 questions
  2. Final Guide:
    • posted this weekend
  3. Grading:
    • assignments 2, 3 this weekend
    • assignments 4, 5 next week


Two Classes of Problems:

P: decision problems solvable in polynomial time

NP: decision problems with a polynomial time verifier

A decision problem $A$ is NP complete if

  1. $A \in $ NP
  2. For every $B \in $ NP, $B \leq_P A$.

Theorem [Cook, Levin]. Boolean Satisfiability (SAT) is NP complete.


  1. More NP Complete Problems
  2. Coping with NP Completeness

Simpler Boolean Formulae


  • a literal is a variable or its negation: $x, \bar{x}$
  • a clause is an expression of the from
    1. $(z_1 \wedge z_2 \wedge \cdots \wedge z_k)$ (conjuctive clause) where each $z_i$ is a literal, or
    2. $(z_1 \vee z_2 \vee \cdots \vee z_k)$ (disjunctive clause) where each $z_i$ is a literal
  • a conjunctive normal form (CNF) expression is an expression of the form $C_1 \wedge C_2 \wedge \cdots \wedge C_\ell$ where each $C_i$ is a disjunctive clause

Observation: a CNF formula evaluates to true $\iff$ all clauses evaluate to true


Definition. A 3-CNF formula is a Boolean formula in conjunctive normal form such that every clause contains 3 literals.


$\varphi(w, x, y, z) = (x \vee y \vee z) \wedge (y \vee \bar z \vee w) \wedge (\bar x \vee \bar y \vee \bar w)$


  • Input: a 3-CNF formula $\varphi$
  • Output: “yes” $\iff \varphi$ is satisfiable

3-SAT is NP-Complete

Theorem (Tseytin 1970). Any Boolean formula $\varphi$ can be efficiently (in polynomial time) transformed into a 3-CNF formula $\psi$ such that:

  1. if $\varphi$ is satisfiable, then so is $\psi$
  2. if $\varphi$ is not satisfiable, then neither is $\psi$


  1. SAT $\leq_P$ 3-SAT
  2. 3-SAT is NP complete


Showing NP Completeness

In order to show a problem $A$ is NP complete, show:

  1. $A \in NP$
    • describe a polynomial time verifier for $A$
  2. $B \leq_P A$ for any NP complete problem $B$
    • describe a polynomial time reduction from $B$ to $A$

IS is NP Complete

Theorem. IS in NP Complete.

Question. What do we need to show?

Strategy. Reduction from 3-SAT

  • show 3-SAT $\leq_P$ IS

Question. How to transform a 3-CNF $\varphi$ into a graph $G$ such that solving IS on $G$ tells us whether $\varphi$ is satisfiable?


$\varphi(w, x, y, z) = (x \vee y \vee z) \wedge (y \vee \bar z \vee w) \wedge (\bar x \vee \bar y \vee \bar w)$

Construction, Formalized


  • 3-SAT formula $\varphi = C_1 \wedge C_2 \wedge \cdots \wedge C_k$
    • clause $C_i = (x_i \vee y_i \vee z_i)$ with $x_i, y_i, z_i$ literals (variables or negated variables)


  • graph $G = (V, E)$ on $n = 3 k$ vertices
    • $V = \{ x_1, y_1, z_1, x_2, y_2, z_2, \ldots, x_k, y_k, z_k\}$
    • edges:
      • for each $i$, $x_i, y_i, z_i$ form a triangle
      • if $x_i = \neg x_j$, add edge $(x_i, x_j)$ (sim. for other variables)

Claim 1

Suppose $\varphi$ a 3-SAT formula with $k$ clauses, $G$ corresponding graph. If $\varphi$ is satisfiable, then $G$ has an independent set of size $k$.

Claim 2

Suppose $\varphi$ a 3-SAT formula with $k$ clauses, $G$ corresponding graph. If $G$ has an independent set of size $k$, then $\varphi$ is satisfiable.


The correspondence $\varphi \to G$ is a polynomial time reduction from 3-SAT to IS.

  • $\implies \text{3-SAT} \leq_P \text{IS}$.
  • $\implies$ IS is NP complete

Previously. Showed Vertex Cover (VC) satisfies IS $\leq_P$ VC

  • $\implies$ VC is NP complete

More Relationships

NP Hard Problems

A problem $A$ is NP Hard if $B \leq_P A$ for some NP-complete problem $B$.


  1. MaxIS and MVC
  2. Traveling Salesperson (TSP)
    • input: weighted graph $G$, set $U$ of vertices
    • output: minimum weight cycle containing all vertices of $U$
  3. Subset Sum
    • input: numbers $w_1, w_2, \ldots, w_n$, target $s$
    • output: subest of numbers that sum to $s$

Coping with NP Hardness

Fact of Life. Many important practical problems are NP-Hard.

Question. So what do we do about it?

Coping Strategies

What if we need to solve an NP hard problem?

  • deal with it: exact (exponential time) algorithms
  • heuristics: no running time or correctness guarantee
    • local search
    • machine learning
  • approximation algorithms: efficient algorithms with guaranteed approximation to optimal
  • parameterized algorithms: classify instances that can be solved efficiently

Where to go from Here?

  1. More algorithms!
    • parallel & distributed algorithms (COSC 273, 373)
    • computational geometry (COSC 225)
    • randomized algorithms
    • streaming and sublinear algorithms
    • approximation algorithms
  2. More complexity!
    • automata/computability theory (COSC 401)
    • computational complexity
    • cryptography
    • models of computation

Thank You!
