# Lecture 24: Weighted Knapsack $\def\opt{ {\mathrm{opt}} }$

## Upcoming

• Week 09: finish dynamic programming
• Week 10: network flow & applications
• Week 11: midterm 2
• Weeks 12, 13: NP completeness

## Overview

1. Finishing Weighted Interval Scheduling
2. The Knapsack Problem

## Weighted Interval Scheduling

Input:

1. A set $R$ of $n$ intervals $r_1 = [s_1, t_1], r_2 = [s_2, t_2], \ldots, r_n = [s_n, t_n]$
2. For each interval $r \in R$, a weight $w(r) > 0$
• e.g., weight = profit from serving request $r$

Output. A collection of intervals from $R$ that is

1. feasible no two intervals overlap
2. maximum weight choice maximizes sum of $w(r)$ for chosen $r$

Note: equivalent to (unweighted) interval scheduling when all weights are the same

## A Recursive Solution

  MaxWeightSchedule(w, p, n):
if n = 0 then return 0
opt-n <- w[n] + MaxWeightSchedule(w, p, p[n])
opt-no-n <- MaxWeightSchedule(w, p, n-1)
return Max(opt-n, opt-no-n)


## Recursion to Iteration

Idea. Store array max:

• max[i] is maximum weight of schedule consisting of intervals $r_1, r_2, \ldots, r_i$

Question. How to initialize/update max values?

## Iterative Solution

  IMaxWeightSchedule(w, p)
max <- new array of size n+1
max <- 0
for i = 1 up to n do
max[i] <- Max(w[i] + max[p[i]], max[i-1])
endfor
return max[n]


Correctness:

• same argument as recursive solution

Running Time?

## Overall Running Time?

Steps: (assume $n$ intervals)

1. Sort intervals by end time

2. Compute array p

3. Run IMaxWeightSchedule(w, p)

Total?

## Exercise

Update IMaxWeightSchedule to return the actual schedule of maximum weight, not just the weight itself.

# The Knapsack Problem

## Knapsack Motivation

In weighted interval scheduling each request had:

• start time
• end time
• value

Goal: to service set of non-overlapping requests to maximize total value

Relaxation. Requests have

• duration
• value

Each request can be scheduled at any time $\leq B$

## Knapsack Problem

Input:

1. A set $R$ of $n$ requests, each having
• duration (weight) $b_r$
• value $v_r$
2. Total time (weight) budget $B$

Output: A set $S$ of requests to service with

1. sum of durations of requests in $S$ is at most $B$
2. sum of values of requests is maximized

Constrained Optimization Problem

• maximize $\sum_{r \in S} v_r$ subject to $\sum_{r \in S} b_r \leq B$

## Recurrence Relation?

Previous technique. Express relationship between optimal solutions that

1. service the final request $r_n$
2. do not service final request $r_n$

Question. How can we express this relationship for the knapsack problem?

## A Recurrence Relation

Subtlety. Must keep track of remaining budget

• if $r_n$ is not serviced, remaining budget is $B$
• if $r_n$ is serviced, remaining budget is $B - b_n$

Definition. For $j = 0, 1, \ldots, n$, $\opt(j, C)$ is optimal value of set of requests from $1, 2, \ldots, j$ with budget $C$.

Question. Recursion relation for $\opt(n, B)$ depending on whether or not we include request $r_n$?

## Computing Optimal Values

Assume. All durations $b_i$ are integers at most $B$.

• we will revisit this assumption later

Compute. To compute $\opt(n, B)$:

• Generate a two dimensional array max where max[j, C] stores the value $\opt(j, C)$

Questions.

1. How to initialize max?
2. How to update max?

## Pseudocode

  FindMax(R, n, B):
max <- new 2d array of dimensions n+1, B+1
set max[0, C] <- 0 for C = 0 to B
for j from 1 to n
(b, v) <- i-th request in R
for C from 0 to B
if b <= C then
max[j, C] <- Max(v + max[j-1, C-b], max[j-1,C])
else
max[j, C] <- max[j-1, C]
return max[n, B]


## Correctness

Claim. For all $j$ and $C$, $\max[j, C] = \opt(j, C)$

Proof. Induction on $j$.

Base case $j = 0$. Optimal subset of size $0$ has value $0$.

Inductive step $j \implies j+1$.

• suppose claim true for all $i \leq j$
• consider two possibilities:
1. request $j+1$ is in optimal subset $S$

$\opt(j+1, C) = v_{j+1} + \opt(j, C - b_{j+1}) = v_{j+1} + \max[j, C - b_{j+1}]$

2. request $j+1$ is not in optimal subset $S$

$\opt(j+1, C) = \opt(j, C) = \max[j, C]$

## Running Time?

  FindMax(R, n, B):
max <- new 2d array of dimensions n+1, B+1
set max[0, C] <- 0 for C = 0 to B
for j from 1 to n
(b, v) <- i-th request in R
for C from 0 to B
if b <= C then
max[j, C] <- Max(v + max[j-1, C-b], max[j-1,C])
else
max[j, C] <- max[j-1, C]
return max[n, B]


## Conclusion

For the knapsack problem with $n$ requests and budget $B$, we can find compute $\opt(n, B)$ in $O(B n)$ time.

• assuming the duration of each request is an integer

## For Next Time

Lecture 25 Ticket. Modify FindMax procedure to return the subset $S$ whose value is $\opt(n, B)$.
