Lecture 05: Mutual Exclusion 3

Outline

  1. Peterson Lock Correctness
  2. Lamport’s Bakery Algorithm
  3. Memory Lower Bounds

Last Time

Introduced the Peterson Lock:

class Peterson implements Lock {
    private boolean[] flag = new boolean[2];
	private int victim;

	public void lock () {
	   int i = ThreadID.get(); // get my ID, 0 or 1
	   int j = 1 - i;          // other thread's ID

	   flag[i] = true;         // set my flag
	   victim = i;             // set myself to be victim
	   while (flag[j] && victim == i) {
	       // wait
	   }
	}

	public void unlock () {
	    int i = ThreadID.get();
		flag[i] = false;
	}
}

Features

Claims:

  1. Peterson satisfies mutual exclusion
  2. Peterson satisfies starvation-freedom
    • stronger than deadlock-freedom
    • previous lock only achieved deadlock-freedom

Proof of Mutual Exclusion I

Suppose not…

  • \(A\) and \(B\) both in critical section (CS) at same time

Proof of Mutual Exclusion II

  • Actions of \(A\):
    • \((A.1)\) writes flag[A] = true
    • \((A.2)\) writes victim = A
    • \((A.3)\) reads flag[B]
    • \((A.4)\) reads victim
  • Actions of \(B\):
    • \((B.1)\) writes flag[B] = true
    • \((B.2)\) writes victim = B
    • \((B.3)\) reads flag[A]
    • \((B.4)\) reads victim

Proof of Mutual Exclusion III

Suppose \((B.2) \to (A.2)\):

  • i.e., \(A\) wrote to victim last

  • if not, continue argument with roles of \(A\) and \(B\) reversed

Timelines

Conclusion

The Peterson lock satisfies mutual exclusion

Proof of Starvation-Freedom I

Suppose not:

  • Some thread runs forever in lock() method
  • Assume it is thread \(A\)
	public void lock () {
	   int i = ThreadID.get(); // get my ID, 0 or 1
	   int j = 1 - i;          // other thread's ID

	   flag[i] = true;         // set my flag
	   victim = i;             // set myself to be victim
	   while (flag[j] && victim == i) {
	       // wait
	   }
	}
  • \(A\) is stuck in while loop

Proof of Starvation-Freedom II

\(A\) stuck in:

	   while (flag[B] && victim == A) {
	       // wait
	   }
  • If \(B\) leaves CS, \(B\) sets flag[B] = false
  • If \(B\) calls lock() again, sets victim = B
  • In in either case, \(A\) eventually breaks out of loop

So

  • Must be that \(B\) also stuck in lock() call

Proof of Starvation-Freedom III

  • Must be that \(B\) also stuck in lock() call
  • But then:
    • flag[B] && victim == A is true (\(A\) in while loop)
    • flag[A] && victim == B is true (\(B\) in while loop)
  • This is a contradiction!
    • victim cannot be both A and B

Conclusion

  • Peterson lock satisfies
    • mutual exclusion
    • starvation-freedom
  • Therefore
    • Peterson lock also satisfies deadlock-freedom

Nice!

But We Want More Threads!

Questions:

  1. What part of Peterson implementation generalizes easily to more threads?
  2. What part doesn’t generalize as easily?

Peterson Lock Code, Again

class Peterson implements Lock {
    private boolean[] flag = new boolean[2];
	private int victim;

	public void lock () {
	   int i = ThreadID.get(); // get my ID, 0 or 1
	   int j = 1 - i;          // other thread's ID

	   flag[i] = true;         // set my flag
	   victim = i;             // set myself to be victim
	   while (flag[j] && victim == i) {
	       // wait
	   }
	}

	public void unlock () {
	    int i = ThreadID.get();
		flag[i] = false;
	}
}

Semantics of Peterson Lock

  • flag variable signals intent to enter CS
    • easily generalizes to more threads
  • victim variable signals priority to enter CS
    • victim = me means you have priority
  • For more threads
    • more victims?
      • how decide priority among victims?
    • how can this system be fair?

Lamport’s Idea for Priority I

Lamport’s Idea for Priority II

After signalling intent to enter CS

  • Take a ticket
    • value of ticket is 1 more than max of others’ tickets
    • thread i sets label[i] to ticket value
  • What is the problem with this?

Breaking Priority Ties

Two processes may see the same set of tickets and take same label:

  • have label[i] == label[j] for i != j

Solution:

Break ties by ID:

  • if label[i] == label[j] and i < j, then i has priority

Use lexicographic order on pairs (label[i], i)

Question About Tie-breaking

Is this process fair?

  • Seems we are always giving priority to thread 0…

Lamport’s Bakery Algorithm

Fields:

  • boolean[] flag
    • flag[i] == true indicates i would like enter CS
  • int[] label
    • label[i] indicates “ticket” number held by i

Initialization:

  • set all flag[i] = false, label[i] = 0

Locking

Locking Method:

public void lock () {
    int i = ThreadID.get();
    flag[i] = true;
    label[i] = max(label[0], ..., label[n-1]) + 1;
    while (!hasPriority(i)) {} // wait
}

The method hasPriority(i) returns true if and only if there is no k such that

  • flag[k] == true and
  • either label[k] < label[i] or label[k] == label[i] and k < i

Unlocking

Just lower your flag:

public void unlock() {
    flag[ThreadID.get()] = false;
}

Bakery Algorithm Guarantees

Bakery Algorithm is Deadlock-Free

public void lock () {
    int i = ThreadID.get();
    flag[i] = true;
    label[i] = max(label[0], ..., label[n-1]) + 1;
    while (!hasPriority(i)) {} // wait
}

Why?

First-come-first-served (FCFS) Property

  • If: $A$ writes to label before $B$ calls lock(),
  • Then: $A$ enter CS before $B$.
public void lock () {
    int i = ThreadID.get();
    flag[i] = true;
    label[i] = max(label[0], ..., label[n-1]) + 1;
    while (!hasPriority(i)) {} // wait
}

Why?

Bakery Algorithm is Starvation-Free

Thread i calls lock():

  • i writes label[i]
  • By FCFS, subsequent calls to lock() by j != i have lower priority
  • By deadlock-freedom every k ahead of i eventaully releases lock

So:

  • i eventually served

Bakery Algorithm Satisfies MutEx

public void lock () {
    int i = ThreadID.get();
    flag[i] = true;
    label[i] = max(label[0], ..., label[n-1]) + 1;
    while (!hasPriority(i)) {} // wait
}

Suppose not:

  • $A$ and $B$ concurrently in CS
  • Assume: $(\mathrm{label}(A), A) < (\mathrm{label}(B), B)$

Proof (Continued)

Since $B$ entered CS:

  • Must have read
    • $(\mathrm{label}(B), B) < (\mathrm{label}(A), A)$, or
    • $\mathrm{flag}[A] == \mathrm{false}$

  • Former can not happen: labels strictly increasing

  • So $B$ read $\mathrm{flag}[A] == \mathrm{false}$

Compare Timelines!

Conclusion

Lamport’s Bakery Algorithm:

  1. Works for any number of threads
  2. Satisfies MutEx and starvation-freedom

Question

Is the bakery algorithm practical?

  • Maybe for few threads…
  • But for many threads?
    • label array contains $n$ indices
    • must read all entries to set own label
    • costly if many threads!
  • Could we do better?

Remarkably

We cannot do better:

  • If $n$ threads want to achieve mutual exclusion + deadlock-freedom, must have $n$ read/write registers (variables)

  • This is really bad if we have a lot of threads!
    • 1,000 threads means each call to lock() requires 1,000s of reads
    • each call to hasPriority requires either 1,000s of reads or a more advanced data structure
  • Things are messy!

A Way Around the Bound

  • Argument relies crucially on fact that the only atomic operations are read and write

  • Modern computers offer more powerful atomic operations

  • In Java, AtomicBoolean class
    • getAndSet()
    • compareAndSet()
  • We will discuss more later

Up Next

Concurrent Objects!
